Model	BE830
Flash	Nor32MB(Reserved), Nand 128MB
DDR4	512MB×1
Antenna	2.4G: 24dBi ; 5G: 24dBi
2.4GHz frequency	2.4GHz ~ 2.484GHz
2.4GHz WIFI protocol	802.11 b / g / n / ax / be
5GHz frequency	5.150GHz～5.850GHz
5GHz WIFI protocol	802.11 a / n / ac / ax / be
Mac rate	2.4GHz: 688Mbps, 5GHz: 2882Mbps
2.4GHz tx power	802.11b	11M	24±2dBm	1M	24±2dBm
	802.11g	54M	22±2dBm	6M	24±2dBm
	802.11n HT20	MCS7	22±2dBm	MCS0	24±2dBm
	802.11n HT40	MCS7	22±2dBm	MCS0	24±2dBm
	802.11ax HE20	MCS11	20±2dBm	MCS0	24±2dBm
	802.11ax HE40	MCS11	20±2dBm	MCS0	24±2dBm
	802.11be EHT20	MCS13	20±2dBm	MCS0	24±2dBm
	802.11be EHT40	MCS13	20±2dBm	MCS0	24±2dBm
5GHz tx power	802.11a	54M	21±2dBm	6M	23±2dBm
	802.11n HT20	MCS7	20±2dBm	MCS0	23±2dBm
	802.11n HT40	MCS7	20±2dBm	MCS0	23±2dBm
	802.11ac VHT20	MCS8	19±2dBm	MCS0	23±2dBm
	802.11ac VHT40	MCS9	19±2dBm	MCS0	23±2dBm
	802.11ac VHT80	MCS9	19±2dBm	MCS0	23±2dBm
	802.11ax HE20	MCS11	18±2dBm	MCS0	23±2dBm
	802.11ax HE40	MCS11	18±2dBm	MCS0	23±2dBm
	802.11ax HE80	MCS11	18±2dBm	MCS0	23±2dBm
	802.11ax HE160	MCS11	18±2dBm	MCS0	23±2dBm
	802.11be EHT20	MCS13	18±2dBm	MCS0	23±2dBm
	802.11be EHT40	MCS13	18±2dBm	MCS0	23±2dBm
	802.11be EHT80	MCS13	18±2dBm	MCS0	23±2dBm
	802.11be EHT160	MCS13	18±2dBm	MCS0	23±2dBm
2.4GHz Receiving sensitivity	802.11b	11M	-89dBm	1M	-95dBm
	802.11g	54M	-75dBm	6M	-92dBm
	802.11n HT20	MCS7	-72dBm	MCS0	-88dBm
	802.11n HT40	MCS7	-70dBm	MCS0	-86dBm
	802.11ax HE20	MCS11	-62dBm	MCS0	-88dBm
	802.11ax HE40	MCS11	-60dBm	MCS0	-86dBm
	802.11be EHT20	MCS13	-60dBm	MCS0	-86dBm
	802.11be EHT40	MCS13	-60dBm	MCS0	-86dBm
5GHz Receiving sensitivity	802.11a	54M	-75dBm	6M	-92dBm
	802.11n HT20	MCS7	-72dBm	MCS0	-88dBm
	802.11n HT40	MCS7	-70dBm	MCS0	-86dBm
	802.11ac VHT20	MCS8	-65dBm	MCS0	-88dBm
	802.11ac VHT40	MCS9	-62dBm	MCS0	-86dBm
	802.11ac VHT80	MCS9	-60dBm	MCS0	-84dBm
	802.11ax HE20	MCS11	-60dBm	MCS0	-90dBm
	802.11ax HE40	MCS11	-58dBm	MCS0	-88dBm
	802.11ax HE80	MCS11	-54dBm	MCS0	-84dBm
	802.11ax HE160	MCS11	-54dBm	MCS0	-82dBm
	802.11be EHT20	MCS13	-54dBm	MCS0	-86dBm
	802.11be EHT40	MCS13	-52dBm	MCS0	-84dBm
	802.11be EHT80	MCS13	-50dBm	MCS0	-82dBm
	802.11be EHT160	MCS13	-48dBm	MCS0	-80dBm
2.4GHz EVM	802.11b: ≤-10 dB；802.11g: ≤-25 dB；802.11n: ≤-28dB；802.11ax: ≤-35 dB; 802.11be: ≤-38 dB
5GHz EVM	802.11a: ≤-25 dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB; 802.11ax: ≤-35 dB, 802.11be: ≤-38 dB
ppm	±20ppm
WAN	1*10/100/1000/2500Mbps WAN, support 802.3at
LAN	1*10/100/1000Mbps LAN
Button	reset
Power supply	PoE 802.3at，DC2.0 12V/2A
Power consumption	<24W
Size	198mm × 198mm × 32mm
Weight	0.9kg
Environment	Operating temperature-10°C to 40°C；Storage temperature: -40°C to 70°C；humidity：5％～95％（No condensation）

BE830
