Flash

Nor32MB(reserved), Nand 128MB

DDR4

512MB×2

2.4G Frequency

2.4GHz - 2.484GHz

2.4G Wi-Fi standard

802.11b/g/n/ax

5G Frequency

5.1G and 5.8G(depend on country/ region)

5G Wi-Fi Standard

802.11 a/n/ac/ax/be

6G Frequency

5.925GHz～7.125GHz

6G Wi-Fi Standard

802.11be

Interface

1 * 10G WAN Port, support 802.3bt PoE input

1 * 10/100 /1000/2500M LAN Port

1 * 10G WAN SFP+ Port

1 * Reset button, press 10 seconds to revert to default setting

2.4GHz/5GHz or 2.4GHz/6GHz

Dual band antenna

Built-in antenna 4pcs, antenna gain: 1.7dBi@2.4GHz, 4dBi@5GHz/6GHz

Data Rate

2.4GHz provides a maximum access rate of 1148Mbps, 5GHz provides a maximum access rate of 2882Mbps, and 6GHz provides a maximum access rate of 5764Mbps, with a total rate of nearly 10Gpbs.

End Users

384

2.4G RF Power

≤ 20±2dBm

5.8G RF Power

≤ 19±2dBm

Power supply

PoE 802.3bt, DC2.0 54V/1A

LED light

SYS: green, always on after system startup

2.4GHz indicator light: green, always on when 2.4GHz is turned on, off when turned off, and flashes when there is data.

5GHz indicator light: blue, 2.4GHz is always on when turned on, off when turned off, and flashes when there is data.

Third frequency indicator light: orange, the third frequency is always on when turned on, off when turned off, and flashes when there is data.

10G optical port indicator light: green light, always on when connected, flashing when there is data

Power Consumption

≤ 60W

Size

Φ218mm×46mm

Weight

0.55KG

2.4GHz Power

802.11b

11M

18±2dBm

1M

20±2dBm

802.11g

54M

18±2dBm

6M

20±2dBm

802.11n HT20

MCS7

17±2dBm

MCS0

20±2dBm

802.11n HT40

MCS7

16±2dBm

MCS0

19±2dBm

802.11ax HE20

MCS11

16±2dBm

MCS0

19±2dBm

802.11ax HE40

MCS11

16±2dBm

MCS0

19±2dBm

5GHz Power

802.11a

54M

17±2dBm

6M

19±2dBm

802.11n HT20

MCS7

17±2dBm

MCS0

19±2dBm

802.11n HT40

MCS7

16±2dBm

MCS0

18±2dBm

802.11ac VHT20

MCS7

17±2dBm

MCS0

19±2dBm

802.11ac VHT40

MCS7

16±2dBm

MCS0

18±2dBm

802.11ac VHT80

MCS9

16±2dBm

MCS0

18±2dBm

802.11ax HE20

MCS11

17±2dBm

MCS0

19±2dBm

802.11ax HE40

MCS11

16±2dBm

MCS0

18±2dBm

802.11ax HE80

MCS11

16±2dBm

MCS0

18±2dBm

802.11ax HE160

MCS11

15±2dBm

MCS0

17±2dBm

802.11be EHT80

MCS13

16±2dBm

MCS0

18±2dBm

802.11be EHT160

MCS13

15±2dBm

MCS0

17±2dBm

6GHz Power

802.11be EHT20

MCS13

16±2dBm

MCS0

18±2dBm

802.11be EHT40

MCS13

16±2dBm

MCS0

18±2dBm

802.11be EHT80

MCS13

15±2dBm

MCS0

17±2dBm

802.11be EHT160

MCS13

14±2dBm

MCS0

16±2dBm

2.4GHz receiver sensitivity

802.11b

11M

-87dBm

1M

-96dBm

802.11g

54M

-75dBm

6M

-93dBm

802.11n HT20

MCS7

-73dBm

MCS0

-92dBm

802.11n HT40

MCS7

-70dBm

MCS0

-89dBm

802.11ax HE20

MCS11

-64dBm

MCS0

-92dBm

802.11ax HE40

MCS11

-61dBm

MCS0

-89dBm

5GHz  receiver sensitivity

802.11a

54M

-74dBm

6M

-92dBm

802.11n HT20

MCS7

-73dBm

MCS0

-90dBm

802.11n HT40

MCS7

-70dBm

MCS0

-87dBm

802.11ac VHT20

MCS7

-67dBm

MCS0

-91dBm

802.11ac VHT40

MCS7

-63dBm

MCS0

-88dBm

802.11ac VHT80

MCS9

-60dBm

MCS0

-84dBm

802.11ax HE20

MCS11

-62dBm

MCS0

-91dBm

802.11ax HE40

MCS11

-59dBm

MCS0

-89dBm

802.11ax HE80

MCS11

-56dBm

MCS0

-86dBm

802.11ax HE160

MCS11

-53dBm

MCS0

-83dBm

802.11be EHT20

MCS13

-52dBm

MCS0

-87dBm

802.11be EHT40

MCS13

-49dBm

MCS0

-85dBm

6GHz  receiver sensitivity

802.11be EHT20

MCS13

-52dBm

MCS0

-87dBm

802.11be EHT40

MCS13

-49dBm

MCS0

-85dBm

802.11be EHT80

MCS13

-46dBm

MCS0

-82dBm

802.11be EHT160

MCS13

-44dBm

MCS0

-79dBm

2.4GHz EVM

802.11b:≤-10 dB ；802.11g: ≤-25 dB ；802.11n:≤-28 dB；802.11ax:≤-35 dB

5GHz EVM

802.11a: ≤-25 dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB;

 802.11ax: ≤-35 dB, 802.11be: ≤-38 dB

6GHz EVM

802.11be: ≤-38 dB

Temperature

Working: -10°C to 40°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)

ESD

Air:±8K, Touch:±4K

Electrical Surge

Common Mode: 2K, Differential Mode: 1K
